FW105

ADDRESSABLE FIRE ALARM CONTROL PANEL

The FW105 Addressable Fire Alarm Panel features a compact design wide enough to fit between 16″ studs. It has a 7″ color LCD sequential screen that can display up to 8 active zones simultaneously.

FIRE ALARM PANEL

The FW105 features one addressable loop circuit (SLC) with 252 addressable devices/points as well as 6 auxiliary function buttons and 12 LED indicators.

Capabilities

Network supports up to 32 panels (Class X) or 109 remote annunciators or panels (Class B)

Compliance

UL/ULC Listed

Built-In Annunciator

Built-in 30 LED/buttons annunciator

  • 10A power dedicate for signaling circuits

  • Comes with 4 NAC that can be expanded to 8 NAC; 2 Amp per circuit

  • 2 RS232, 1 USB, and 1 RJ45 port on the panel

  • 4 Optional SLC isolator circuits available (Expandable to 8 isolators Class B)
